F15

Thin Cutting Frame Saw

1/1

+ DESCRIPTION

Designed For Profitable Production

  • The F15 Thin-Cutting Frame Saw from Mick & Jack is designed and engineered to enhance the high efficiency and high accuracy cutting. In addition to provide various cutting modes, the F15 also features great material-cost saving that creats profits for customer. The machine is equipped with a micro-computer control for maximum operational convenience.

Various Sawblades For Choice

  • Upon request, the machine can be supplied with steel welded sawblade or T.C.T. sawblade for choice.

  • The customer may choose various sawblade thickness from 0.9 to 1.4 mm to suit various wood materials.

+ SPECIFICATIONS

All specifications, dimensions, and design characteristics shown in this catalog are subject to change without previous notice.

+ FLOW CHART

01

Sawblade Air Blast

The air blast device provides cooling to the sawblades for extending blades service life. In addition, the device also can remove saw dust existed in blade teeth ensuring high quality cutting at all times.
Stable Cutting : The wood to be cut is supported steadily, ensuring high stability of cutting.

02

Centralized Pressure Regulations

Each pressure roller is equipped with independent pressure regulator for individual air pressure adjustment.All pressure regulation valves are centralized for convenient adjustment and maintenance.

03

Micro-computer Control

The machine is equipped with a PLC control for maximum operation convenience. Electronic components and circuit design fully meet CE safety regulations. Comprehensive anti-interference protection devices. Self-diagnostic functions and warning lamp displays.

04

Guide Fence At Side

In case the guide fence is mounted at the side, the machine allows for cutting a single wood material.

05

Multiple Guide Fence

Upon request, the machine is available to supply with several guide fences. Fence sizes can be specified by customer. The use of multiple guide fence enables the machine to cut several wood materials at a time.

06

Guide Fence At CenterPosition

In case the guide fence is mounted atthe center position, the machine allows for cutting two wood materials at a time for increasing efficiency.

+ FEATURES

Fine Surface

Extremely fine surface effect after cutting which permits direct glue jointing for saving 0.15mm sanding tolerance.

Accurate Thickness Of Cut



High accuracy thickness of cut is ±0.1mm. No gapping problem on the cut surface.

Reduced wood material Loss



Wood cutting performed by the frame saw may reduce material loss to a minimum for saving production cost.

Saving Cost



The frame saw reduces material loss to a minimum. It saves 20% wood material when comparing with that by a conventional machining method.

Rigid Saw Frame



The saw frame is a rigid construction, assuring extremely fine surface effect of cutting and high thickness accuracy of cutting.

​*Choice of various saw frames

+ APPLICATION

01Thin wood

02 Toy: Airplane model

03 Musical Instrument : Guitar

04 Stationery: pencil

05 Sporting Goods: Ski

06

Composite flooring, stair plate and venetian blind
